DS200DPCBG1A power connection card
Product Manual：
#DS200DPCBG1A power connection card
1. Responsible for the transfer and distribution of various power signals within the rack.
2. Adapt to the turbine control rack and connect to the system backplane bus.
3. Multiple power channels are used to allocate power to each functional board.
4. Circuit isolation design to avoid mutual interference between power circuits.
5. Industrial grade PCB board, capable of withstanding complex working conditions in power plants.
6. Onboard status indicator light, visually viewing the power supply working status.
7. Integrated overcurrent protection to reduce damage to the board caused by load faults.
8. Equipped with circuit detection, quickly locate power supply faults.
9. Standard slot specifications, easy to insert and remove.
10. Collect input power and distribute it to various sub functional modules.
11. Compatible with redundant power configurations to enhance the reliability of the entire machine’s power supply.
12. Small power supply voltage drop ensures stable power supply voltage for each board.
13. Simplify the wiring inside the cabinet and optimize the layout of the power supply chain.
14. The board layout is compact, saving installation space inside the rack.
15. Convenient on-site replacement and shortened equipment downtime for maintenance.
This DS200DPCBG1A power connection card is used in the power generation turbine industrial control system to complete power collection, distribution, and circuit switching.
