DSQC346G 3HAB8101-8 Robot Servo Drive Unit
Product Manual：
DSQC346G 3HAB8101-8 robot servo drive unit is a dedicated single axis servo drive for ABB’s old-fashioned robot control cabinet. It is responsible for motor power output and motion closed-loop control, with stable operation and strong driving force.
1. Original ABB servo drive unit, model DSQC346G 3HAB8101-8
2. Suitable for S4, S4C, S4C+series robot control cabinets
3. Single axis independent drive, controlling the operation of robot joint servo motors
4. Integrated current, speed, and position triple closed-loop regulation function
5. Built in multiple safety protections for overvoltage, overcurrent, overheating, and short circuit
6. Receive encoder feedback signals, accurately locate trajectory control
7. Cabinet slot installation, stable docking, easy and convenient disassembly and assembly
8. Industrial grade circuit design, earthquake resistant, dynamic and electromagnetic interference resistant
9. Adequate load driving force, compatible with multi specification robot joint axes
10. Dynamic response sensitive, smooth start stop action without impact
11. Wide working condition temperature resistant design, capable of long-term continuous full load operation
12. Comes with a built-in fault indicator light, making it easy to quickly troubleshoot and locate issues
13. Original factory precision board, low failure rate, long service life
14. Replace directly with the same model without the need for complex parameter debugging and settings
15. Widely used for handling, welding, and spraying old-fashioned robotic equipment
The DSQC346G 3HAB8101-8 servo drive unit has high control accuracy and complete protection performance, and is a core commonly used accessory for single axis fault maintenance and spare parts replacement of ABB’s old robots.
