EDWARDS AVALUE LPC-1203 Touchscreen Panel

Product Manual：

EDWARDS AVALUE LPC-1203 Touchscreen Panel Product Features
EDWARDS AVALUE LPC-1203 is compatible with Edward Vacuum Equipment’s exclusive control terminal
12.1-inch industrial resistive touch screen, wear-resistant, scratch resistant, and not prone to screen smudging
The whole machine has no fan for heat dissipation, reducing the probability of dust accumulation and failure
IP65 sealed protection on the front, moisture-proof and oil proof, suitable for clean workshops
High brightness LED backlight, clear and visible data in strong light environments
Equipped with multiple serial port communication, it can be connected to vacuum gauges and main control devices
Dual network port independent channel, separate transmission of process data and operation instructions

Comes with a CF card storage slot for easy backup of vacuum operation records
Waterproof laminated physical buttons, not easily damaged by short circuits when operated with wet hands
Aluminum alloy integrated body, corrosion-resistant and resistant to volatile gases from vacuum pumps
Modular motherboard design, no need for complete machine replacement for later hardware upgrades
Multi channel IO expansion interface, linked valve and pump start stop control
Built in hardware watchdog, program freezes and automatically restarts for recovery
Embedded standard opening, quick disassembly and replacement to save downtime
Pre installed Edward vacuum matching program, directly access pump set parameters
EDWARDS AVALUE LPC-1203 touch screen panel is a dedicated human-machine operation terminal for vacuum semiconductor equipment

Product detailed pictures：

LPC-1203

product video
