EDWARDS YT76-Z2-Z20 Controller Unit

Product Manual：

EDWARDS YT76-Z2-Z20 Controller Unit
Introduction: EDWARDS YT76-Z2-Z20 is a dedicated controller for vacuum pumps, which provides stable control and is suitable for continuous operation of semiconductor vacuum equipment.
Precise control of vacuum pump start stop and speed adjustment
Real time monitoring of vacuum pressure and operational load data
Equipped with multiple safety protections against overcurrent, overheating, and overload
Signal isolation circuit, resistant to electromagnetic interference in the workshop
Standard wiring port, easy to disassemble and replace
The indicator light visually displays the running and alarm status

Industrial grade components, resistant to dust and slight vibrations
Supports remote communication and can be connected to the device’s main control system
Power on automatic self check, quickly identify fault points
Wide temperature working range, stable operation of the production line in a constant temperature environment
Compact size, saving installation space for control cabinets
Compatible with multiple dry pump and molecular pump units from Edwards
Multiple sets of vacuum process parameters can be set and saved
Fault record storage, convenient for later maintenance and repair
Low operating power consumption, more energy-efficient for long-term use
Conclusion: EDWARDS YT76-Z2-Z20 has complete functions and high reliability, and is a core control spare part for vacuum systems.

Product detailed pictures：

YT76-Z2-Z20
