Erhardt+Leimer DRS2202 Network Guidance System

Product Manual：

Erhardt+Leimer DRS2202 Network Oriented System
Introduction: Erhardt+Leimer DRS2202 web correction network control system, suitable for various web production lines, with stable correction control.
DRS2202 has built-in industrial network communication and can be connected to the centralized control system of the production line
High precision correction control, high-speed feeding is less prone to deviation and wrinkling
Compatible with various infrared and ultrasonic coil detection probes
Real time uploading of operational data for convenient on-site viewing of work status
Internal circuit with isolation protection, resistant to workshop electromagnetic interference
Brushless drive structure, low operating noise and minimal loss

The device comes with alarm prompts, and faults can be quickly located
The system responds sensitively, and there is no delay in high-speed production line calibration
Standard 24V industrial power supply, easy to adapt production line wiring
Compact overall structure, small installation space occupied by equipment
Sealed metal shell, dustproof and moisture-proof, suitable for coating and printing workshops
Split modular structure, separate replacement and repair for local damage
Multiple DRS2202 can be networked for synchronous collaborative work
Adapt to high and low temperature production environments, operate continuously and stably for a long time
Conclusion: Erhardt+Leimer DRS2202 is commonly used in film, lithium battery, and printing roll production lines, and has strong practicality for networked correction.

Product detailed pictures：

DRS2202

product video
