FI830F 3BDH000032R1 fieldbus module
Product Manual：
FI830F (model 3BDH000032R1) is a dedicated PROFIBUS-DP master fieldbus module for ABB AC800F/Freelance DCS system, used to connect controllers with PROFIBUS-DP slave devices and achieve high-speed real-time communication.
Model: FI830F, order number 3BDH000032R1, ABB original.
Protocol: PROFIBUS-DP V1, compliant with DIN 19245 standard, master station mode.
Interface: RS-485, standard DP bus terminal, supports redundant master station.
Baud rate: 9.6 kbps~12 MBd, adaptive, with a maximum communication distance of 1000 meters.
Slave capacity: up to 126 DP slaves, supporting large network architectures.
Working voltage: 24 VDC (± 10%), backplane power supply, low power consumption.
Working temperature: -25 ℃~+60 ℃, storage -40 ℃~+85 ℃.
Size and weight: 125 × 28 × 155 mm, approximately 0.26 kg, single slot compact.
Installation: DIN rail/rack installation, compatible with AC800F rack, hot swappable.
System adaptation: Matched with PM802F/PM803F controllers, seamlessly integrated into Freelance DCS.
Data interaction: Periodic I/O data+non periodic diagnosis, supporting DP-V1 expansion function.
Redundancy capability: Supports dual module redundant master stations, automatic fault switching, and improves reliability.
Diagnosis and maintenance: LED status indication (RUN/ERR), supporting remote diagnosis and fault location.
Protection level: IP20, industrial grade anti vibration, anti EMI interference.
Application scenarios: Widely used in process control fields such as chemical, power, water treatment, metallurgy, etc. that require highly reliable DP communication.
FI830F 3BDH000032R1， As the core DP master module of ABB DCS system, it is the preferred solution for industrial fieldbus communication due to its high speed, large capacity, redundancy and reliability.
