G122-829-001 servo amplifier

Product Manual：

MOOG G122-829-001 PI servo amplification module, guide rail servo valve drive controller.
DIN rail buckle installation, quick fixing of cabinet
Built in dialing, optional proportional, integral, PI composite control mode
Compatible with ± 10V, 4-20mA multi specification control input
Output ± 10/20mA current, direct drive servo valve coil
Adjustable potentiometer on the panel, quick on-site gain adjustment
LED status indicator light for intuitive troubleshooting of circuit faults
Multi channel signal aggregation operation, precise adjustment of closed-loop error
24VDC power supply, low power consumption and stable operation of the whole machine

Wide temperature design, suitable for workshop working conditions at -20~+70 ℃
10. Comes with testing points, no need to disassemble the casing to measure signals
11. Anti electromagnetic interference circuit, adapted to the surrounding environment of the frequency converter
12. Modular compact shell, saving cabinet installation space
13. Analog circuit architecture, fast response and high control accuracy
14. Commonly used in injection molding, papermaking, and hydraulic precision closed-loop equipment
15. Factory aging testing, hydraulic system with spare parts for replacement
ending
G122-829-001 is a specialized driver amplifier for hydraulic servo valves, which achieves high-precision closed-loop control of the equipment.

Product detailed pictures：

G122-829-001
