HIMA Z7306 shunt adapter

Product Manual：

Z7306 is an analog input splitter adapter for HIMA HIMatrix safety control system, used for analog signal access between F35 controller and F3 AIO 8/4 01 remote I/O.
Model: HIMA Z7306, Material Number 98 2220115.
Positioning: Specialized plug-in splitter module for simulating input in security systems.
Core function: Provides 250 Ω shunt resistor, supports HART communication, and overvoltage protection.
Diverting resistance: 250 Ω, accuracy of 0.1%, temperature drift of 25ppm/° C.
HART: Built in 250 Ω HART specific resistor.
Power: Single channel maximum power consumption 0.4W（ 40mA@250 Ω).
Protection: Overvoltage protection, maximum 40mA/24V.
Environment: Working temperature is 0-60 ℃, storage temperature is -40-85 ℃.

Size: 35 × 23 × 25mm, plug-in installation.
Terminals: Sa/Sb (transmitter power supply), Ia+/Ib+(analog input), Ia -/Ib – (reference pole).
Protection: Surface coating, dustproof and moisture-proof.
Adaptation: F35 safety controller, F3 AIO 8/4 01 remote I/O.
Application: 4-20mA transmitter connection, supporting HART devices.
Wiring: Suitable for connecting transmitters with line resistance RL<30 Ω.
Safety: Compatible with SIL level safety system signal acquisition.
Z7306, with high-precision shunt and HART support, has become a key adaptation module for analog signal access in HIMA safety systems.
