IC693MDL753 Programmable Controller Module

Product Manual：

IC693MDL753 is a 32 point high-density DC output module of GE Fanuc 90-30 series PLC, suitable for industrial automation control systems.
32 independent transistor outputs, divided into 4 groups with 8 points each, isolated in groups.
Rated 12/24VDC, voltage range 10.2-28.8VDC.
0.5A per point, maximum 4A per group, common pin 3A.
Positive logic source output, current flows to the load, and wiring is simple.
Fast response speed, with a typical on-off delay of 0.5ms.
Strong surge resistance, capable of withstanding 5.4A surge current within 10ms.
Low power consumption, with a backplane 5V power supply of only 260mA.

High isolation, 1500VAC on site and logic side, 250VAC between groups.
Each channel is equipped with independent LEDs for clear and visible status.
On state voltage drop ≤ 0.3V, off state leakage current ≤ 0.1mA.
Industrial wide temperature design, suitable for working conditions from -20 ℃ to+60 ℃.
Standard PLC rack installation, easy to plug and maintain.
Anti vibration, high and low temperature resistance, stable and reliable long-term operation.
No need for fans, natural heat dissipation, reducing failure points.
Compatible with GE 90-30 series PLC, seamless and easy to integrate.
Overall, IC693MDL753 has high output density, strong isolation performance, and stable operation, making it the preferred module for industrial I/O control.

Product detailed pictures：

IC693MDL753
