IOC4T 200-560-000-018 Mechanical Protection Card
Product Manual：
IOC4T 200-560-000-018 is a mechanical protection I/O card for VM600 system, used for rotating equipment status acquisition and interlocking control.
15 characteristics
1. Configure four signal acquisition channels that can access vibration and displacement sensing signals.
2. 200-560-000-018 is compatible with standard analog signal output, making it easy to interface with central control DCS systems.
3. Equipped with multiple relay contacts, it triggers warning or shutdown interlock actions when exceeding the limit.
4. Equipped with a digital output interface, it is convenient for external expansion of alarm control circuits.
5. Built in anti-interference filtering circuit, suitable for complex electromagnetic environments in industrial sites.
6. Support online plugging and maintenance, without the need for the entire equipment to be shut down for maintenance.
7. It can export the original collected waveform for easy troubleshooting and debugging of equipment.
8. Equipped with programmable control functions such as alarm bypass and remote reset.
9. Industrial grade component selection ensures continuous and stable operation in a wide temperature environment.
10. Relying on backplane bus communication, data transmission and response to the main control board are fast.
11. Terminal fastening type wiring ensures that the on-site circuit connection is firm and not easily loose.
12. Adhere to industrial electromagnetic compatibility standards and meet the security regulations for heavy industry equipment.
13. The board structure is streamlined, with less occupied rack slots, making it easier for system expansion.
14. After long-term aging testing at the factory, the overall machine has a low failure rate during operation.
15. IOC4T is suitable for security projects of large units such as steam turbines, air compressors, and fans.
ending
IOC4T 200-560-000-018 is a commonly used supporting board for vibration security control systems in industrial units.
Product detailed pictures：
IOC4T 200-560-000-018
