IS200TBCIS2CCD Discrete Input/Contact Terminal Board
Product Manual：
IS200TBCIS2CCD is a discrete input/contact terminal board specifically designed for GE Mark VI/VIe series turbine control systems. It is used for dry contact signal acquisition and system interface, ensuring stability and reliability.
Compatible with GE Mark VI/VIe/VIeS control system, seamlessly integrated into the system backplane.
Provide 24 independent dry contact input channels, supporting 24VDC/125VDC excitation configuration.
Double group barrier terminal block (TB1/TB2), each with 24 wiring terminals, easy to connect.
Channel group isolation design, resistant to on-site electromagnetic interference, resulting in purer signals.
Each channel is equipped with a built-in filtering circuit to suppress high-frequency noise and surges, and improve signal stability.
It supports simplex and the third mock examination redundancy (TMR) system architecture and adapts to highly reliable scenarios.
Equipped with LED status indicator lights, it intuitively displays the working status of channels and power supply.
Support fault diagnosis and status reporting for quick identification of anomalies.
Industrial wide temperature operation, stable operation in an environment of -30 ℃~65 ℃.
Backboard power supply (5VDC/24VDC), no additional external power supply required.
Modular design, supporting plug-in terminal blocks, easy maintenance and replacement.
Compatible with input modules such as IS220PDIA and IS200YDIA, with strong scalability.
Through UL/cUL, CE and other industrial safety certifications, it is compliant and reliable.
ending:
IS200TBCIS2CCD has become the core terminal board for dry contact signal acquisition in gas/steam turbine control due to its high isolation, strong anti-interference, and system level compatibility characteristics.
