IS200TDBTH6ACD Discrete input/output terminal board
Product Manual：
IS200TDBTH6ACD Discrete Input/Output Terminal Board
IS200TDBTH6ACD is a discrete input/output terminal board in the GE Mark VIe system, used for on-site switch signal access and relay output control. It is a key interface board in gas turbine and industrial automation control systems.
Product Features:
Belongs to GE Mark VIe system discrete I/O terminal board
Used for on-site switch signal input acquisition
Support multiple digital input channels
Provide relay output control function
The input signal adopts isolation design to improve safety
Support 24V DC industrial standard signal access
Capable of withstanding surges and high-frequency interference
Built in signal filtering and suppression circuit
Support for use in conjunction with PDIO I/O modules
Communicate with the controller through the system bus
Can be used for TMR redundant control architecture
The module supports multi-point on-site wiring
Industrial grade design, suitable for high vibration environments
Flexible installation method (rail or rack)
High signal stability, suitable for continuous operation systems
Summary:
The IS200TDBTH6ACD discrete input/output terminal board is mainly used for industrial field signal acquisition and control output, and is an important interface component for connecting field equipment and controllers in GE gas turbine control systems.
Product detailed pictures：
IS200TDBTH6ACD
