IS215VCMIH2CC communication card
Product Manual：
IS215VCMIH2CC communication card
1. GE OEM VME bus control card, compatible with Mark VI gas turbine control system
2. Integrated RS232 and three IONet network ports, multi-channel synchronous communication transmission
3. 32-bit DSP main control chip, fast data calculation, communication response in milliseconds
4. Manage the address allocation of all I/O boards within the control rack and coordinate the data exchange of the entire machine
5. Multiple sets of status indicator lights on the panel for intuitive visualization of operation and faults
6. Hardware built-in signal isolation circuit to resist electromagnetic interference at power plant sites
7. Standard C-type VME slot, rail plug-in installation, easy disassembly and replacement
8. Three proof coating on the entire board, dustproof and moisture-proof, suitable for high temperature working conditions in power plants
9. Equipped with a built-in board self-test program, it can quickly locate and alert for line faults
10. Responsible for system IONet networking, connecting the main control and peripheral field devices
11. Wide temperature component selection, stable operation in the range of -20 ℃~70 ℃
12. Onboard data cache, retaining critical communication log information during short-term power outages
13. Compatible and interchangeable with the same series of cards, simple and universal selection of spare parts
14. Low power circuit layout, not prone to overheating during long-term continuous operation
15. Dedicated to the main control system of thermal power and gas turbines, with excellent industrial control stability
In summary, the IS215VCMIH2CC communication card is the core board for achieving complete communication interconnection of GE Mark VI units.
Product detailed pictures：
IS215VCMIH2CC
