Jeol 170A118681-D control module
Product Manual：
Jeol 170A118681-D control module
1. 170A118681-D is equipped with JEOL JWS 7855S electron microscopy energy spectrum detection system for use
2. Control the collection, processing, and signal analysis of energy spectrum data
3. Accurate signal acquisition, stable recording of weak X-ray signals
4. Built in overvoltage and electrostatic protection to prevent hardware damage in high voltage environments
5. Rack mounted standard structure, with the chassis slot directly fixed for installation
6. Anti cavity electromagnetic interference, ensuring smooth operation of the equipment during operation
7. Docking the detector with the main control board to complete data transfer calculation
8. Can continuously collect and analyze data online for a long time without downtime
9. Original dedicated wiring port, no need to modify the wiring for docking
10. The overall heat generation is moderate, and the enclosed chassis has stable heat dissipation
11. The board surface is moisture-proof and dustproof, suitable for enclosed working environments of instruments
12. Metal frame reinforcement, earthquake resistant, collision resistant, and not easily damaged components
13. Equipped with an external control panel for intuitive viewing of status
14. Comes with easy self check, hardware faults can be quickly located
15. 170A118681-D is compatible with the original factory’s complete machine program and can be put into production by replacing it in situ
In summary, 170A118681-D is a dedicated control module for energy spectrum matching electron microscopy, responsible for energy spectrum signal acquisition and calculation, and is often used for spare parts replacement and maintenance of old models.
Product detailed pictures：
170A118681-D
