JEOL AP001116-01 Video Control Module

Product Manual：

JEOL AP001116-01 video control module is compatible with JSM-6701F scanning electron microscope, responsible for image signal conversion and video output control.
1. Original components, compatible with JEOL JSM-6701F field emission scanning electron microscope
2. Receive the original image signal from the detector and complete the video signal format conversion
3. Adjust basic imaging parameters such as image brightness and contrast
4. Isolation design of signal lines to reduce image noise caused by scanning interference
5. Built in signal filtering circuit ensures stable video output quality
6. Standard slot installation, easy disassembly and replacement operation
7. Integrated electrostatic protection circuit, protecting signal processing chip
8. Electromagnetic shielding structure to resist electromagnetic interference in laboratory environment

9. Industrial grade components, supporting long-term continuous observation of equipment
10. Output standardized video signals to the console display terminal
11. Real time feedback on video link status, identifying signal interruption faults
12. Equipped with overvoltage and surge protection to reduce the risk of hardware failure
13. The board has good stability and is less affected by temperature and humidity changes
14. Layout of signal channel zoning for easy troubleshooting of fault points
15. Parameter calibration is completed after delivery, and debugging is simple after replacement
The JEOL AP001116-01 video control module is a key component of the electron microscopy imaging link, which enables the conversion and output of raw detection signals to visualized images.

Product detailed pictures：

AP001116-01
