MJEOL AP001129-01 Operator Interface Panel

Product Manual：

The JEOL AP001129-01 operator interface panel is the original control component of JSM-6701F scanning electron microscope, which enables local manual operation of the instrument.
1. Original accessories, compatible with JEOL JSM-6701F scanning electron microscope
2. Equipped with joystick and function buttons, manually adjust the sample stage
3. Fast transmission of operation instructions and sensitive control response
4. Signal isolation design to avoid interference with electron microscopy imaging
5. Anti static structure to protect internal precision circuits
6. Integrated module, easy to disassemble and replace
7. Electromagnetic shielding, suitable for laboratory electromagnetic environment

8. Durable buttons, supporting long-term frequent operation
9. Bidirectional communication, synchronized feedback on device operation status
10. Built in circuit protection to reduce the probability of failure
11. Strong adaptability to temperature and humidity, stable operation
12. The interface layout is well-organized for easy maintenance and repair
13. Factory pre calibration, low workload for replacement and debugging
14. Equipped with safety interlocks to ensure the safe operation of equipment
15. Compact structure, suitable for instrument installation space
The JEOL AP001129-01 operator interface panel serves as a human-machine interaction component for local adjustment of sample stage displacement and imaging parameters.

Product detailed pictures：

AP001129-01
