JEOL AP002117 High Voltage Control Board
Product Manual：
JEOL AP002117 High Voltage Control Board
1. Compatible with JEOL electron microscope high-voltage power supply system, JEOL AP002117 precisely regulates high-voltage output parameters
2. Equipped with multiple high-voltage protection circuits, it has overvoltage, overcurrent, and arc detection protection
3. JEOL AP002117 has high output voltage stability and excellent voltage ripple control
4. High voltage and low voltage signal partition wiring effectively suppresses electromagnetic interference
5. Industrial grade high-voltage components, supporting long-term continuous operation of instruments
6. Rapid signal response, capable of quickly completing high-voltage start stop and adjustment
7. Built in state detection circuit, easy to quickly locate high-voltage circuit faults
8. Compact board structure, saving internal assembly space of equipment chassis
9. Standard positioning installation hole, easy to disassemble, replace and maintain operation
10. Wide temperature tolerance characteristics, adapted to the temperature fluctuation environment inside the mirror body
11. Strict insulation design standards to eliminate the risk of high voltage leakage
12. Specification for metalized via holes in multi-layer boards, with stable and reliable strong and weak electrical conductivity
13. Original factory control protocol matching, no additional debugging parameters required
14. Good anti vibration performance, and the parameters of the equipment are not easily drifting during operation
15. The interface specifications are factory standardized and can be connected to high-voltage generating components
The JEOL AP002117 high-voltage control board, as the core component of high-voltage regulation, is used in conjunction with JEOL series electronic optical precision instruments.
