JEOL AP002126-01 Processor PCB Card
Product Manual：
JEOL AP002126-01 processor PCB card is compatible with JSM-6701F scanning electron microscope, responsible for overall operation, signal processing, and module scheduling.
1. Original factory board, matched with JEOL JSM-6701F field emission scanning electron microscope
2. Undertake core computing tasks and coordinate the coordinated operation of various functional boards
3. High speed processing of various collected signals to ensure stable imaging timing
4. Precise wiring design to reduce signal interference and avoid affecting image quality
5. Built in signal filtering circuit to suppress clutter noise
6. Slot installation, easy and fast disassembly and replacement
7. Anti static protection, protecting onboard precision chips
8. Electromagnetic shielding structure, suitable for laboratory electromagnetic environment
9. Industrial grade components that support long-term continuous operation of instruments
10. Real time reception of operational instructions and issuance of control signals
11. Equipped with fault recognition function, providing timely feedback on abnormal working conditions
12. Integrate multiple circuit protection to reduce the risk of hardware damage
13. The substrate is stable and can withstand fluctuations in environmental temperature and humidity
14. Clear line zoning for easy troubleshooting
15. High dimensional accuracy, direct replacement without complex calibration
The JEOL AP002126-01 processor PCB card is the core computing carrier of the scanning electron microscope control system, which realizes the processing of machine instructions and data exchange.
Product detailed pictures：
