JEOL AP002210-01 Controller Board
Product Manual：
JEOL AP002210-01 controller card is compatible with JSM-6701F scanning electron microscope and is responsible for closed-loop control of the actuator.
1. Original board, compatible with JEOL JSM-6701F field emission scanning electron microscope
2. Receive master control instructions and manage the operation of the sample stage drive unit
3. Collect position sensing signals and complete real-time position closed-loop adjustment
4. Signal isolation wiring to avoid motion interference with image signals
5. Built in signal filtering to suppress circuit noise
6. Standard slot installation, quick disassembly and replacement
7. Integrated electrostatic protection to protect the main control chip
8. Electromagnetic shielding structure, suitable for laboratory working conditions
9. Industrial components that support long-term continuous operation of equipment
10. Real time feedback on position and limit status information
11. Equipped with fault self check, quickly identify communication abnormalities
12. Equipped with overcurrent and overvoltage protection circuits
13. Stable substrate performance and resistance to temperature and humidity fluctuations
14. Line partition layout, convenient for fault maintenance
15. Factory calibration in place, easy installation and debugging
The JEOL AP002210-01 controller board mainly realizes precise control of the displacement of the scanning electron microscope sample stage.
Product detailed pictures：
