JEOL AP002821-01 Image Processing Module

Product Manual：

JEOL AP002821-01 image processing module is compatible with JSM-6701F scanning electron microscope, responsible for detector image signal acquisition, operation processing, and image output.
1. Original module, matched with JEOL JSM-6701F field emission scanning electron microscope
2. Receive secondary electron and backscattered electron detection signals
3. Real time completion of image denoising and contrast signal processing
4. Precise circuit layout to reduce signal noise interference in imaging
5. Built in signal filtering circuit to ensure image signal-to-noise ratio
6. Slot installation, easy and fast disassembly and replacement
7. Anti static protection, protecting onboard precision chips

8. Electromagnetic shielding structure, suitable for laboratory electromagnetic environment
9. Industrial grade components that support long-term continuous operation of instruments
10. High speed signal conversion, real-time output of scanned images
11. Capable of identifying signal anomalies and providing timely feedback on faults
12. Integrate multiple circuit protection to reduce the risk of hardware damage
13. Stable substrate performance and resistance to temperature and humidity fluctuations
14. Clear division of lines for easy troubleshooting
15. High dimensional accuracy, direct replacement without complex calibration
The JEOL AP002821-01 image processing module is the core component of electron microscopy imaging, which processes raw detection signals and transmits images to the display terminal.

Product detailed pictures：

AP002821-01

product video
