JEOL AP003739-00S Vacuum Control Board

Product Manual：

JEOL AP003739-00S Vacuum Control Board
1. Compatible with JEOL precision equipment and meets the original factory vacuum system control standards
2. JEOL AP003739-00S vacuum control board collects vacuum pressure sensor signals
3. Real time control of vacuum valve and vacuum pump start stop logic
4. Equipped with voltage protection circuit to prevent board failures caused by surges
5. JEOL AP003739-00S vacuum control board has built-in filtering to reduce electromagnetic signal interference
6. Adapt to the temperature fluctuation environment inside the device cavity
7. Standard board size, slot installation, easy replacement

8. High sensitivity of pressure monitoring, accurate identification of vacuum degree changes
9. JEOL AP003739-00S vacuum control board uses industrial components and supports continuous operation
10. Comes with abnormal alarm signal output, making it easy to detect vacuum faults in a timely manner
11. The wiring definition is consistent with the original accessories, and can be directly replaced without changing the wiring
12. Line insulation design to avoid leakage and short circuit risks
13. JEOL AP003739-00S vacuum control board has completed vacuum linkage testing before leaving the factory
14. Stable execution of automated processes such as vacuum pumping and pressure maintenance
15. Low operational failure rate, reducing spare parts replacement costs
The JEOL AP003739-00S vacuum control board controls the entire vacuum system, ensuring a stable vacuum environment in the JEOL equipment chamber.

Product detailed pictures：

AP003739-00S
