JEOL BP-100918-01 Vacuum Relay Module
Product Manual：
1. JEOL BP-100918-01 Vacuum Relay Module Control Vacuum Air Circuit On/Off Switching
2. Relying on vacuum negative pressure to drive contact opening and closing, avoiding arc erosion problems
3. Quick response and precise execution of on/off instructions given by the host
4. Embedded card installation, disassembly and maintenance do not require significant disassembly of the unit
5. Low no-load power consumption, slight temperature rise during long-term on duty operation
6. Adapt to the complete vacuum chamber gas path control operation of the electron microscope
7. Excellent seismic performance, equipment operation vibration is not easily triggered by mistake
8. Connect to the control system of the whole machine, and the signal can be connected to work together
9. Equipped with self-locking status, it can maintain the current on/off state after power failure
10. On/off control operation for vacuum pipelines in semiconductor equipment
11. Isolation of strong and weak control circuits to prevent mutual interference between circuits
12. Can operate continuously for a long time under normal temperature and humidity conditions in the computer room
13. Internal sealing structure, making it difficult for dust and water vapor to enter the internal contacts
14. Automatically lock when the load exceeds the standard, protecting the core components of the module
15. JEOL BP-100918-01 vacuum relay module has passed the factory test and verification, and can be put into use immediately after installation
JEOL BP-100918-01 vacuum relay module stably controls the vacuum circuit on and off, with a long service life and safe and stable operation.
Product detailed pictures：
BP-100918-01
product video
