JEOL BP101552-02 Power Inspection Board

Product Manual：

JEOL BP101552-02 Power Inspection Board
1. Supporting the use of JEOL electron beam equipment power supply monitoring system
2. JEOL BP101552-02 power inspection board real-time monitoring of various output voltages
3. Multiple independent sampling circuits are used to collect data from different power channels
4. Built in filtering circuit to eliminate noise interference during voltage sampling process
5. The board specifications are consistent with the original spare parts and support direct replacement installation
6. Comparison between measured voltage and standard threshold of JEOL BP101552-02 power inspection board
7. Capable of identifying overvoltage and undervoltage, monitoring abnormal power supply conditions
8. Optimize the sampling circuit to improve the accuracy of voltage detection

9. The definition of connector pins is completely consistent with the original board
10. Long term uninterrupted monitoring ensures that sampling performance is not prone to drift
11. Send an alarm signal to the main control in a timely manner when the power supply is abnormal
12. Adapt to the working environment of a constant temperature and dust-free electron microscope room
13. The sampling lines of each power supply circuit are independent of each other, which facilitates maintenance
14. Rapid voltage sampling feedback, shortening fault response time
15. Follow JEOL original circuit design and manufacturing standards
The JEOL BP101552-02 power inspection board is responsible for monitoring the overall power status of the machine, promptly detecting power supply faults, and ensuring the safe operation of the equipment.
