Jeol BP101884-00 detects high voltage module

Product Manual：

Jeol BP101884-00 detects high voltage module
1. Compatible with JEOL electron microscopy high-voltage detection system
2. Jeol BP101884-00 detects high voltage module and collects real-time high voltage data
3. High precision voltage sampling with small measurement errors
4. Built in isolation circuit to protect against high voltage breakdown risk
5. Original factory standard specifications, can be directly replaced and used
6. Jeol BP101884-00 detects high voltage module to suppress high voltage signal clutter
7. Equipped with dual protection mechanisms for overvoltage and overcurrent
8. High voltage signal conversion is stable, and the output waveform is smooth

9. Original interface definition, no need to modify wiring
10. Support long-term uninterrupted monitoring and operation of equipment
11. Real time upload of high voltage abnormal signal to the main control
12. Adapt to the constant temperature working environment in the equipment room
13. Modular structure, convenient fault maintenance
14. Fast signal response speed, no significant delay in monitoring
15. Follow the original high-voltage electrical safety standards
The Jeol BP101884-00 detection high-voltage module is responsible for monitoring the high-voltage circuit of the equipment, ensuring the stable operation of the entire high-voltage system.

Product detailed pictures：

BP101884-00
