JEOL BP102105 panel PB board

Product Manual：

JEOL BP102105 panel PB board
1. Compatible with JEOL precision equipment, with original factory standard panel interface specifications
2. JEOL BP102105 panel PB board is responsible for signal conversion of the operation panel
3. Optimizing PCB routing to reduce signal crosstalk
4. Built in basic protective circuit to resist voltage fluctuations
5. Fast signal transmission response and stable human-machine command transmission
6. The grounding layout is complete and has good anti-interference ability
7. Industrial substrate, suitable for continuous temperature changes in the chassis environment
8. Accurate external dimensions, can be directly disassembled and replaced

9. JEOL BP102105 panel PB board connection button, indicator light signal circuit
10. Line partition layout to reduce signal interference with each other
11. The solder joints are firm and not prone to virtual soldering during long-term operation
12. Clear wiring for easy maintenance of fault points
13. Configure electrostatic protection to protect electronic components
14. Connector adapter panel cable, smooth insertion and removal
15. Ensure normal panel interaction and reduce equipment downtime
The JEOL BP102105 panel PB board is a dedicated adapter circuit board for human-machine operation panels.
