JEOL SP-000454-00 Input/Output Module
Product Manual：
JEOL SP-000454-00 Input/Output Module
1. Adapt to the safety and motion control circuit of JEOL precision electron beam equipment
2. JEOL SP-000454-00 input/output module is responsible for controlling the transmission and reception of switch signals
3. Multiple independent IO channels, separate processing of feedback signals and drive instructions
4. Design of photoelectric isolation circuit to block mutual interference between high and low voltage circuits
5. Modular standard specifications, chassis slots can be directly replaced for assembly
6. JEOL SP-000454-00 Input/Output Module Compatible with Whole Machine Switch Signal Standard
7. Built in surge absorbing components to protect against transient voltage impact damage to channels
8. Optimize internal circuit layout to reduce signal transmission jitter
9. The definition of terminal pins is consistent with the original components, and there is no need to change the wiring
10. Under long-term high-frequency on-off conditions, channel performance is not easily degraded
11. Channel short circuit and open circuit faults can be actively reported to the main control system
12. Stable adaptation to the constant temperature and dust-free working environment of the electron microscope room
13. Partition arrangement of input and output channels, simple and efficient fault location
14. Rapid response of signal on/off, ensuring accurate timing of equipment interlocking
15. Compliant with JEOL original hardware security design specifications
The JEOL SP-000454-00 input/output module serves as a switch signal interaction unit, completing equipment interlocking and external mechanism signal transmission work.
Product detailed pictures：
