KAWASAKI 3NS004S-C008 Robot Laser Module
Product Manual：
KAWASAKI 3NS004S-C008 Robot Laser Module
beginning
KAWASAKI 3NS004S-C008 is a specialized laser positioning module for Kawasaki Semiconductor robotic arms, mainly used for precise wafer alignment detection to ensure the positioning accuracy of robot handling operations.
lass=”yoast-text-mark” />>Product Features
Laser beam concentration, high detection and positioning accuracy
Fast response speed, able to quickly complete wafer alignment calibration
Metal sealed shell, dustproof and moisture-proof, suitable for clean workshops
Built in multiple circuit protections to prevent damage from overvoltage and overcurrent
Anti electromagnetic interference, stable adaptation to complex electromagnetic environments of equipment
Compact and compact in size, the installation space of the robot end is small
Standardized interface design, simple wiring, easy disassembly and assembly
Equipped with self checking function for easy and quick troubleshooting
Low operating power consumption, low heat generation during long-term continuous operation
Stable laser output and small measurement data error
The original electrical parameters are unified, and the same series of models have good replaceability
Anti static structure design to prevent static electricity from damaging optical components
Wide temperature working design, stable operation in both high and low temperature environments
Beam attenuation resistance, stable detection effect after long-term use of equipment
Compatible with Kawasaki NS series wafer handling robots, highly versatile
summary
KAWASAKI 3NS004S-C008 robot laser module has precise positioning, reliable protection, and convenient installation. It is a core component for high-precision alignment in semiconductor wafer automation handling, which can effectively improve equipment operation stability and production yield.
Product detailed pictures：
3NS004S-C008
