Kyosan Electric 2L80-000558-V1 power module
Product Manual：
Kyosan Electric 2L80-000558-V1 power module
Introduction: Kyosan Electric 2L80-000558-V1 is a high-voltage power module specifically designed for semiconductor equipment, suitable for powering TEL etching film machines.
Original HV-PS8 high voltage solution, output DC3300V stable high voltage
Standard 24V DC input, compatible with workshop general power supply specifications
Constant current and constant voltage output, with small voltage fluctuations and low ripple
Equipped with DeviceNet bus, it can communicate with the device controller
Local control interface, supporting manual debugging of on-site parameters
Multi state indicator light, intuitive display of power/standby/alarm
Built in multiple protection circuits for overvoltage, overcurrent, and short circuit
Automatic power reduction due to overheating, not easily damaged in high temperature environments
All metal sealed shell, dust-proof and suitable for dust-free workshops
High voltage output dedicated interface, insulation and leakage prevention are safer
Digital precise voltage regulation, controllable output values with high precision
Low arc suppression design ensures stable wafer processing
Standardized docking port, easy and fast disassembly and replacement
Lightweight integrated structure, space saving for cabinet installation
Long cycle continuous operation to meet the uninterrupted operation of the production line
Conclusion: Kyosan Electric 2L80-000558-V1 has stable high-voltage output and is a core power supply spare part for semiconductor coating and etching equipment.
Product detailed pictures：
2L80-000558-V1
