LIS 073320-183-25E processor module
Product Manual：
LIS 073320-183-25E processor module
LIS 073320-183-25E is a dedicated clock control processor board for Orbotech automatic optical inspection equipment, used for PCB exposure machine timing operation and motion logic scheduling.
1. Original compatible with Orbotech Paragon series testing equipment, with precise slot size matching
2. Dedicated clock processing chip, high-precision output device synchronous timing signal
3. High speed data computation, synchronous processing of image acquisition and platform motion instructions
4. Multiple isolated IO channels on board, connected to servo, light source, and sensor components
5. Built in multi-stage circuit protection against overcurrent, overvoltage, and static electricity
6. Metal shielded circuit to isolate equipment from radio frequency electromagnetic interference
7. Industrial wide temperature substrate, stable and uninterrupted operation for a long time
8. Sinking gold finger plug interface, easy disassembly and maintenance
9. Independent fault self checking circuit, indicator light quickly locates abnormal channels
10. Partition strong and weak electrical wiring to avoid signal interference and distortion
11. Lead free environmentally friendly board, suitable for dust-free PCB production workshops
12. Reinforce surface mount components to prevent virtual soldering in equipment vibration environments
13. Standardized communication terminals, connected to the main control system of the entire machine
14. Compact card insertion structure, cabinet card slot saves installation space
15. Support local calibration of timing parameters, debugging does not require disassembly of the entire machine
In summary, the LIS 073320-183-25E processor module has precise timing and stable operation, making it the core control board for PCB exposure and optical detection equipment.
Product detailed pictures：
073320-183-25E
