LOGOSOL LPA812-3-V76C1 pre aligner

Product Manual：

LOGOSOL LPA812-3-V76C1 pre aligner
Introduction: LOGOSOL LPA812-3-V76C1 is a pre alignment equipment specifically designed for semiconductor wafers, with precise positioning and suitable for continuous processing on dust-free production lines.
High precision visual positioning, precise recognition of wafer edges and gaps
Vacuum adsorption fixed wafer, placed firmly and not easily displaced
Non contact detection to avoid scratching the thin film on the wafer surface
Servo driven operation with minimal vibration and low repeat positioning error
The whole machine meets high cleanliness standards and is suitable for dust-free workshop conditions
Real time status monitoring, automatic alarm prompts for missing or damaged pieces

Built in multiple electrical protections, automatic protection against overcurrent and overheating
Standard communication interface, compatible with device control system
Modular structure, easy to operate for maintenance and replacement of parts
Fast response speed during operation, shortening the cycle time for single piece processing
Isolation circuit design to resist on-site electromagnetic interference
Compact and compact body, saving installation space inside the device
Wide temperature stable operation, suitable for long-term operation in a constant temperature environment in the workshop
Automatic self inspection of the whole machine upon power on, quickly troubleshooting optical path drive faults
Durable original parts, low failure rate during long-term continuous operation
Conclusion: LOGOSOL LPA812-3-V76C1 is a clean, durable, and stable positioning equipment that is a key supporting device for wafer transfer processes.

Product detailed pictures：

LPA812-3-V76C1
