MagneTek MG2-1F-3FE power supply module
Product Manual：
MagneTek MG2-1F-3FE power supply module
Introduction: MG2-1F-3FE is an industrial grade AC-DC switching power supply module from MagneTek, specifically designed to provide high reliability DC power supply for industrial control, communication, and automation equipment, supporting redundant parallel expansion.
1. Model MG2-1F-3FE, original from the United States, CE/UL/RoHS certified.
2. Wide voltage input 100-240VAC, 50/60Hz, compatible with global industrial power grids.
3. Input current of 18A, maximum output power of 1000W, stable under heavy load conditions.
4. Standard output 24VDC, current 13-25A, voltage accuracy better than ± 1%.
5. Conversion efficiency of 85% -90%, low loss, high power density.
6. Support hot plugging, parallel connection of multiple modules, and can build N+1 redundant systems.
7. Built in protection against overvoltage, overcurrent, short circuit, and overheating, with automatic fault recovery.
8. Forced air cooling for heat dissipation, suitable for enclosed cabinets and high ambient temperature scenarios.
9. Industrial grade design, working temperature -10 ℃~+50 ℃, strong anti-interference.
10. Metal chassis, sturdy structure, dustproof and shockproof, suitable for harsh environments.
11. Panel LED indicator light, real-time display of power/fault status for easy troubleshooting.
12. Optional output of normal signals, supporting remote monitoring and alarm linkage.
13. Support hot swapping, maintenance and replacement without downtime, improving system availability.
14. Standard cabinet installation, compact size saves space inside the cabinet.
15. Widely used in industrial control, communication, robotics, and automation production line power supply.
Conclusion: MG2-1F-3FE is the preferred module for industrial high reliability DC power supply due to its core advantages of wide voltage adaptation, high efficiency and stability, redundant expansion, and multiple protections.
Product detailed pictures：
product video
