MEGA-F 00000-2019-000-801 Linear Servo Drive
Product Manual：
MEGA-F 00000-2019-000-801 Linear Servo Drive
Introduction: MEGA-F 00000-2019-000-801 is a fully digital linear servo drive module specifically designed for semiconductor testing equipment
Pure linear output without dead zone, low motion noise, high positioning accuracy
Support complete closed-loop control of torque, speed, and position
40kHz high-speed sampling, adjustable current loop bandwidth up to 7kHz
Peak 30A high current output, suitable for linear and voice coil motors
48V DC standard power supply, optional 100V high voltage version
Compatible with analog ± 10V and SPI main control signal inputs
Support feedback from multiple encoders, including digital and sine cosine encoders
Equipped with optocoupler isolation IO, limit, enable signal stability and anti-interference
Built in dynamic braking function, emergency stop quickly locks the load
Equipped with USB debugging port and supporting software for one click self-tuning of parameters
Equipped with large heat sinks, it can run at full load for a long time without high temperature
Multiple fault protection for short circuit, overcurrent, overvoltage, and overheating
Compact board structure, standard slot for direct replacement installation
Factory compatible wafer inspection and precision optical motion platform
Low electromagnetic interference, suitable for high-precision processes in clean workshops
Conclusion: MEGA-F 00000-2019-000-801 has high control accuracy and strong stability, and is a specialized drive spare part for linear motion of precision equipment
Product detailed pictures：
00000-2019-000-801
