Mitsubishi HG-KR43-S131046 servo motor
Product Manual：
Mitsubishi HG-KR43-S131046 is a Mitsubishi J4 series 400W low inertia AC servo motor, suitable for automated precision positioning equipment
1. Mitsubishi HG-KR43-S131046 is matched with MR-J4-40 driver, and the overall compatibility is strong
2. Rated power 400W, rated torque 1.3Nm, peak torque 4.5Nm, fast start stop response
3. Built in 22 bit absolute value encoder, single turn 4194304 pulse, extremely high positioning accuracy
4. Low inertia rotor design, maximum speed 6000rpm, high-speed reciprocating motion without hysteresis
5. 60 × 60 standard flange installation, compact body, saving equipment installation space
6. The whole machine has IP65 protection, dustproof and waterproof, and is suitable for normal working conditions in the workshop
7. 200V AC power supply, rated current 2.6A, excellent energy consumption control
8. Straight axis standard output, can be quickly assembled with couplings and synchronous wheels
9. Natural heat dissipation structure, stable temperature rise during long-term full load operation
10. Gold plated wiring terminals, difficult to contact due to repeated insertion and removal
11. Anti vibration and anti-interference, suitable for semiconductor and detection equipment electromagnetic environment
12. No built-in brake version, lightweight body weight 1.4kg
13. Standard rectangular power supply/coding dual connector, with neat wiring that is not easy to loosen
14. Support origin memory, no need to reset to zero after power failure and restart
15. Industrial grade winding magnetic steel, with a low failure rate for 7 × 24-hour continuous operation
Conclusion: Mitsubishi HG-KR43-S131046 is a high-speed, high-precision, and compact driver component for XY platforms and visual equipment
Product detailed pictures：
HG-KR43-S131046
product video
