MKS AS01496-AB-4 Control Board

Product Manual：

MKS AS01496-AB-4 Control Board
Introduction: MKS AS01496-AB-4 is a dedicated original signal control board for semiconductor vacuum equipment, which controls the gas path and vacuum sensing signals
Compatible with MKS vacuum gauge, flow controller and complete machine
Multi channel signal synchronous acquisition, precise pressure and flow data acquisition
Multi layer shielded circuit to resist electromagnetic interference in the workshop
Strong and weak current zoning wiring reduces the risk of short circuit leakage
Gold plated solder pad contacts, stable and non oxidizing contact after long-term use
Standard backplane plug-in design, can be directly replaced without changing the wiring
Reserved testing points for quick and convenient troubleshooting

Built in signal filtering, stable output signal without clutter
Support multiple communication protocols and interface with device control systems
Comes with fault records for easy traceability and troubleshooting of process issues
High temperature resistant industrial substrate, stable long-term operation in clean workshops
Multiple circuit protection, automatic shutdown protection for overcurrent and overvoltage
Small board structure, cabinet slot installation saves space
Full process aging testing at the factory, with low failure rate during operation
The silk screen point identification is clear, and the disassembly and wiring are not prone to errors
Conclusion: MKS AS01496-AB-4 signal control has strong stability and compatibility, and is a replacement spare for semiconductor vacuum process core

Product detailed pictures：
