NI PCI-6561 Analyzer Module
Product Manual：
The NI PCI-6561 analyzer module is a NI high-speed LVDS digital waveform generation/analysis card, suitable for precision testing scenarios of digital circuits and communication interfaces.
Model PCI-6561, genuine NI original product
Integrated 16 channel LVDS, differential signal transmission
Maximum 100MHz clock, DDR rate up to 200Mb/s
2/16/128MB onboard memory optional per channel
Support SDR/DR dual-mode and adapt to different speeds
Built in SMC synchronization core, multi device synchronization with low jitter
High precision timing, with a sampling resolution of up to 10ps
Multi time clock source: internal VCXO, external CLK, STROBE
Capable of hardware triggering and mode scheduling
Standard PCI interface, compatible with industrial computer slots
3 SMB+12X InfiniBand interfaces, flexible connection
Strong anti-interference ability, good suppression of LVDS differential signal noise
Industrial grade temperature range 0-45 ℃, long-term stable operation
Adapt to digital testing, communication interfaces, IC verification, etc
Strict factory calibration, NIST traceable accuracy
The NI PCI-6561 analyzer module is the preferred core board for digital waveform testing and analysis due to its high speed, high precision, and strong synchronization capability.
