Orion ETN23A-SC-B Heat Exchanger

Product Manual：

Orion ETN23A-SC-B Heat Exchanger
1. Special plate heat unit for semiconductor equipment
2. High heat transfer efficiency and excellent temperature control accuracy
3. Corrosion resistant channel material, compatible with ultrapure water cooling medium
4. Channel optimization with low medium flow resistance
5. Reliable sealing structure to prevent coolant leakage
6. Strong pressure bearing capacity, able to withstand pressure fluctuations in waterways
7. Compact size, suitable for small spaces inside the machine
8. Fast thermal response, quickly offsetting changes in equipment thermal load

9. Clean treatment of inner walls to meet the standards of dust-free workshops
10. Less prone to scaling, reducing maintenance and cleaning frequency
11. Temperature monitoring points with inlet and outlet ports
12. Anti vibration and impact, suitable for long-term continuous operation of production lines
13. Standardized pipeline interface, easy disassembly and replacement
14. Whole machine sealing testing to ensure the safety of vacuum equipment
15. Adapt to the temperature control and heat dissipation circuit of etching and coating equipment
Orion ETN23A-SC-B heat exchanger is a thermal management component for semiconductor machines, responsible for heat exchange of process components and stabilizing equipment operating temperature.

Product detailed pictures：

ETN23A-SC-B
