PANASONIC MSMD022P2S AC servo motor

Product Manual：

PANASONIC MSMD022P2S AC servo motor product features
Introduction: PANASONIC MSMD022P2S small AC servo motor, used for precision transmission positioning of semiconductor equipment.
Compact and lightweight body, occupying minimal installation space on the device
High precision encoding device, high repeatability positioning accuracy
Adequate low-speed torque, smooth operation without shaking
Rapid dynamic response, sensitive acceleration and deceleration switching
The whole machine is sealed and dustproof, suitable for clean production workshops
Low running noise, no noise during long-term operations
Equipped with multiple protections against overload, overheating, and step loss

Standard flange installation, easy disassembly and replacement
Compatible with Panasonic servo drives, high compatibility
Supports multiple pulse control methods, easy to debug
Winding reinforcement process, long anti vibration service life
Stable torque output, suitable for high-frequency reciprocating motion
Gold plated wiring terminals, reliable anti-oxidation connection
Good heat control and sustainable long-term operation
Suitable for wafer handling and precision fine-tuning platform equipment
Conclusion: PANASONIC MSMD022P2S AC servo motor outputs precise power to ensure stable operation of semiconductor equipment transmission processes.

Product detailed pictures：

MSMD022P2S

product video
