PI E711E0118 Printed Circuit Board

Product Manual：

PI E711E0118 printed circuit board is compatible with precision industrial automation equipment.
1. Multi layer high-density wiring, suitable for narrow installation spaces of equipment
2. Precise impedance control, low transmission loss of high-frequency signals
3. Large area copper grounding to reduce on-site electromagnetic interference
4. Multiple sets of thermal conductive vias for long-term full load heat dissipation balance
5. Sinking gold solder pads, multiple soldering is not easy to oxidize and virtual solder

6. Strong and weak electrical zoning wiring, isolating power supply noise interference
7. Differentiate the length of the line to reduce signal crosstalk delay
8. High heat-resistant PI substrate, suitable for alternating cold and hot working conditions
9. Reserve shielding points to enhance the anti-interference performance of the entire machine
10. Precise microporous process, stable and durable interlayer conductivity
11. Specialized moisture-proof solder mask, dust-proof, corrosion-resistant and aging resistant
12. Component reinforcement patch, capable of withstanding continuous vibration of equipment
13. Standard original factory circuit, matched with corresponding complete machine system
14. Built in anti-static circuit to protect onboard precision chips
15. Unified positioning holes, easy and convenient disassembly and replacement
The PI E711E0118 printed circuit board stably transmits control signals to ensure the continuous operation of the equipment.
