Reliance Electric 805401-5R Power Module Interface Rack
Product Manual：
The Reliance Electric 805401-5R is an AutoMax control system power module installation rack that integrates power distribution and bus docking functions.
1. Model 805401-5R, Ryan original factory matching interface installation base.
2. The slots are arranged in a regular manner to secure the power supply and various control boards.
3. Built in backplane bus to achieve signal interconnection and transmission between modules.
4. Equipped with filtering components to filter out power grid clutter and reduce line interference.
5. Equipped with a cooling fan to optimize internal cooling conditions under high load conditions.
6. Centralize the wiring of the communication circuit and allocate working power to the plug-in modules uniformly.
7. Metal frame structure, earthquake resistant and durable, suitable for workshop vibration conditions.
8. The standard cabinet size can be directly fixed inside the industrial control cabinet.
9. Reserve external wiring terminals for easy connection of on-site instrument circuits.
The working range is 10.0-55 ℃, which meets the continuous operation of the equipment 24/7.
11. Perfectly compatible with the entire range of AutoMax power and IO control accessories.
12. Simplify the overall wiring layout for easy troubleshooting and maintenance in the future.
13. It is commonly used in old multi motor transmission and self-control equipment for papermaking and steel rolling.
14. The original factory has long ceased production, and replacement of faults relies on the supply of disassembled spare parts.
The integrated design is reliable and practical, and the 805401-5R is a key spare part for Ryan’s old-fashioned transmission system.
Product detailed pictures：
805401-5R
