Rexroth EA-4/10/MX-2 Printed Circuit Board
Product Manual：
Rexroth EA-4/10/MX-2 Printed Circuit Board
Rexroth EA-4/10/MX-2 is a dedicated drive control board for Rexroth hydraulic proportional valves, compatible with 4/10 diameter proportional valves and MX series electromagnets. It is responsible for signal conditioning and current closed-loop drive, and is widely used in hydraulic systems such as injection molding/forging/metallurgy/machine tools.
Specialized adaptation: Designed specifically for Rexroth 4/10 proportional valves and MX electromagnets, with high compatibility.
Standard signal: Supports 0- ± 10V, 4-20mA, compatible with mainstream PLCs.
Closed loop control: Current closed-loop regulation, precise output without drift, good linearity.
Wide voltage power supply: Operating at 24VDC, resistant to voltage fluctuations, suitable for industrial power supply.
Multiple protections: overcurrent/short circuit/overload, extending coil life.
Wire breakage detection: signal wire breakage diagnosis and fault feedback for easy maintenance.
Adjustable parameters: onboard potentiometer, on-site fine-tuning of zero point and gain.
Industrial grade PCB: earthquake resistant, anti-interference, oil resistant, suitable for harsh working conditions.
Standard interface: European style pins, with standardized wiring and reliable insertion and removal.
Compact design: Standard electrical control box installation, saving space.
Strong driving: Stable driving of proportional valve electromagnet, fast response.
Original factory quality: Long term continuous stable operation with low failure rate.
Status visualization: LED indicator light, quick fault location.
Slope adjustment: Soft start/stop to reduce hydraulic shock.
Convenient replacement: original compatible, plug and play, reducing downtime
Product detailed pictures：
EA-4/10/MX-2
