RTD1 1MRS050644 Printed Circuit Board

Product Manual：

RTD1 1MRS050644 printed circuit board is an ABB original temperature acquisition board with stable operation.
Original factory standard board, dedicated to thermal resistance signal acquisition
Support platinum thermistor connection, suitable for conventional temperature measurement scenarios
Multi channel design, capable of simultaneously collecting multiple temperature data channels
High sampling accuracy, precise and reliable temperature measurement data
24V DC power supply, low power consumption and smooth operation
Equipped with electrical isolation, excellent anti-interference and lightning protection performance
Industrial wide temperature design, suitable for various on-site environments

Onboard status indicator light, visually visible for operational faults
Standard slot installation, easy to disassemble and replace
Modular structure, compatible with control systems of the same series
High quality PCB board, earthquake resistant and moisture-proof, with a long service life
Compliant with industry safety standards and possessing relevant certifications
Stable signal conversion ensures normal data transmission
Low operational difficulty, quick troubleshooting in case of malfunctions
Widely used in temperature measurement circuits for power, petrochemical, and metallurgical industries
This board has excellent temperature measurement performance and is a commonly used accessory for industrial temperature monitoring systems.

Product detailed pictures：

RTD1 1MRS050644

product video
