Sanritz Automation SVP501-3-P10 Signal Board
Product Manual：
Sanritz Automation SVP501-3-P10 Signal Board
Introduction: Sanritz Automation SVP501-3-P10 is a Japanese made 8-channel IO signal processing board specifically designed for semiconductor equipment
Equipped with 8 independent digital signal channels, synchronously collecting device sensing signals
Dual network communication design, stable docking with the main control system of the machine to transmit data
Multi layer shielded precision circuit, resistant to electromagnetic interference in the workshop without clutter
Gold plated solder pad terminal, stable contact and not easily oxidized during long-term operation
PMC standard slot specifications, cabinet direct insertion replacement does not require modification
Built in signal filtering chip ensures pure input and output signals
Strong and weak current zoning wiring reduces the risk of short circuit and leakage faults
Reserve multiple sets of testing points for quick and convenient troubleshooting
Suitable for semiconductor processes such as wafer etching and cleaning
Industrial high temperature resistant substrate, clean workshop operates continuously 24/7
Multiple circuit protection on board, automatic shutdown protection for overcurrent and overvoltage
Clear silk screen component identification, less prone to errors in disassembly and wiring
Large capacity cache chip, signal transmission and reception without delay or packet loss
Original factory aging verification, low failure rate of the entire machine during operation
Made in Japan with original packaging, the same model of board can be directly compatible and replaced
Conclusion: Sanritz Automation SVP501-3-P10 has stable signal transmission and strong compatibility, and is a core IO signal spare part for semiconductor equipment
Product detailed pictures：
SVP501-3-P10
