Siemens 10414999 Interface Isolation Component

Product Manual：

Siemens 10414999 Interface Isolation Component
Introduction: Siemens 10414999 is a specialized interface isolation board for Siemens CT medical equipment, which isolates strong and weak electrical signals to ensure stable acquisition of imaging signals by imaging equipment.
Electrical isolation design, isolating high and low voltage circuits, protecting precision chips on the motherboard
Filter out electromagnetic clutter in the computer room to avoid image distortion caused by signal drift
Multi channel independent isolation, with no crosstalk between channels
Integrated surge and short circuit protection to resist voltage surges
Suitable for CT machine 24V standard power supply circuit
Dedicated docking terminal, connecting the detector to the main control board
Onboard operation indicator light, quickly diagnose circuit faults

Multi layer shielded PCB, medical anti-interference level meets the standard
Moisture proof and anti-corrosion coating, suitable for constant temperature environment in hospital computer rooms
Small board structure, cabinet slot direct insertion installation
Standard gold finger interface, disassembly and replacement without changing the wiring
Transmission of image sampling signals, stable data transmission without loss
Medical wide temperature components, stable long-term continuous startup
Original factory uniform size, direct exchange of spare parts of the same model
Factory CT online aging test for complete machine, high reliability
Conclusion: Siemens 10414999 has reliable isolation protection and is a core original circuit spare part for repairing Siemens CT scanners.

Product detailed pictures：

10414999
