SIEMENS 10830000/D304 Printed Circuit Board
Product Manual：
SIEMENS 10830000/D304 Printed Circuit Board
Introduction: SIEMENS 10830000/D304 is a dedicated control PCB board for Siemens vascular imaging equipment, responsible for the coordinated processing of machine motion and signals.
Original factory compatible Axiom Artis series imaging medical equipment
Multi layer industrial flame-retardant PCB, not easily deformed during long-term operation
Partition routing separates analog and digital signals, with strong anti-interference capabilities
Gold plated contact terminals, difficult to oxidize after repeated insertion and removal, poor contact
Integrated motor drive signal processing, control rack motion positioning
Multi channel signal acquisition channel, synchronously reading sensor data
Onboard static electricity and overcurrent protection components to prevent chip damage
Reserved maintenance and testing points for quick and intuitive troubleshooting
Equipped with status indicator lights, operation and alarm are clear at a glance
Three proof coating coverage, moisture-proof and dustproof, suitable for the environment of the computer room
Balanced heat dissipation through holes, stable temperature control under high loads
Standard slot size, no need for modification for cabinet direct installation
Original supporting underlying program, no need to recalibrate after replacement
Low signal transmission delay, precise synchronization of imaging equipment movements
Support 24-hour uninterrupted continuous stable work
Conclusion: SIEMENS 10830000/D304 signal processing is stable and reliable, and is a spare part for the core circuit board of Siemens imaging equipment maintenance and replacement.
Product detailed pictures：
10830000/D304
