Silicon Graphics 80266B2-01 Central Controller Module
Product Manual：
Silicon Graphics 80266B2-01 Central Controller Module
1. Original 80266B2-01 Plug in Central Control Module
2. Integrated main control computing chip, used in conjunction with 80266 series accessories
3. Onboard storage chip, storing device control firmware programs
4. Multiple sets of high-speed bus contacts, connecting the backplane with various functional daughter cards
5. Built in voltage stabilization protection circuit to resist damage to devices caused by voltage fluctuations
6. Three proof coating on circuit board, dustproof and moisture-proof, suitable for industrial computer room environment
7. Equipped with a status indicator light, quickly troubleshoot hardware faults in the 80266B series
8. Hardware watchdog design, automatic restart and reset when the device crashes
9. Optimize inner layer wiring to reduce control signal transmission loss
10. Wide temperature industrial components, capable of long-term continuous full load operation
11. Reserve test solder joint positions for easy circuit maintenance and parameter debugging
12. Standardized board size, rail type plug-in and easy disassembly
13. Multi channel communication port, connecting peripherals, sensors, and driver components
14. Products of the same specification 80266B2 model can be directly exchanged and replaced
15. Common spare parts for repairing and renovating old industrial control equipment
In summary, the Silicon Graphics 80266B2-01 central controller module is the core component for overall computing and logical control of the entire device.
Product detailed pictures：
80266B2-01
