SONY 4S050-678 power module
Product Manual：
SONY 4S050-678 power module
Introduction: SONY 4S050-678 is a dedicated multi output switch power board for semiconductor testing equipment, which provides stable power supply for internal control and imaging components.
Multi channel DC stabilized output, suitable for different power supply requirements of cameras and main control boards
Wide communication input range, suitable for various power supply environments in the workshop
Independent voltage stabilization circuit, with small voltage fluctuations and pure power supply for each channel
Integrated hardware protection for overvoltage, overcurrent, short circuit, and overheating
Automatically restore output after the fault is resolved, reducing the frequency of downtime maintenance
Built in EMI filtering circuit to suppress workshop RF electromagnetic interference
Equipped with a small heat dissipation structure, the temperature rise during load operation is controllable
Metal shielding shell, isolating clutter and protecting precision imaging circuit
Sinking gold terminal pads, not easily oxidized after long-term use in clean workshops
Standard board size, quick disassembly and replacement of cabinet card slots
Onboard status indicator light, visually identifying the location of power failure points
Multi layer isolated PCB wiring, strong and weak electrical signals do not interfere with each other
Three proof coating protection, moisture-proof and dust-proof, suitable for dust-free production lines
Support 24-hour uninterrupted and long-term continuous operation
Compatible with Sony semiconductor wafer optical inspection machine
Conclusion: SONY 4S050-678 has stable output and complete protection, and is the core power supply module of semiconductor visual inspection equipment.
Product detailed pictures：
4S050-678
