TC625 3BSE002224R1 coaxial modem
Product Manual：
TC625 3BSE002224R1 coaxial modem
TC625 3BSE002224R1 is an ABB AF100 fieldbus dedicated industrial coaxial modem, mainly used for coaxial network signal conversion and long-distance stable communication between DCS system controllers and IO devices.
1. TC625 is tailor-made for ABB AF100 bus architecture, with strong network compatibility
2. 3BSE002224R1 realizes bidirectional modulation and demodulation of digital signals and coaxial analog signals
3. Standard BNC interface, compatible with industrial 75 Ω coaxial cables
4. TC625 supports high-speed data transmission to meet the real-time control communication needs of industry
5. 3BSE002224R1 has long-distance transmission capability and is suitable for cross regional cabling in the factory area
6. Metal shielded body design, TC625 has excellent anti electromagnetic interference performance
7. Adopting 24VDC industrial wide voltage power supply, suitable for on-site power grid fluctuation conditions
8. 3BSE002224R1 industrial wide temperature operation, stable operation in both high and low temperature environments inside the cabinet
9. Equipped with power supply, operation, transmission/reception, and fault indicator lights, the working condition status is intuitively visible
10. TC625 supports online hot plugging of modules, maintenance and replacement do not require system shutdown
11. Native compatibility with AF100 exclusive communication protocol, no additional conversion required for configuration docking
12. 3BSE002224R1 standard guide rail installation method, compatible with conventional industrial control cabinets
13. Low power circuit architecture, suitable for 24/7 uninterrupted continuous operation conditions
14. Dustproof and moisture-proof protection design, able to withstand dusty and humid environments in chemical and electrical industries
15. The overall structure is sturdy and earthquake resistant, and TC625 is not prone to loosening or failure during long-term operation
The TC625 3BSE002224R1 coaxial modem is a core supporting module for ABB DCS system coaxial bus networking communication, with stable communication, strong anti-interference, and wide adaptability.
