TDE MACNO AC/DC50 Industrial Drive

Product Manual：

TDE MACNO AC/DC50 Industrial Drive
1. AC/DC dual-purpose input, supporting two power supply modes: AC grid and DC bus
2. IGBT power architecture, suitable for DC motor and brushless motor speed control
3. Double closed-loop digital regulation of current loop and speed loop, stable torque output
4. Support encoder feedback to achieve high-precision speed and position control
5. Panel buttons and display units, on-site parameter modification, status reading
6. Multi channel digital input and output, realizing the interaction of start stop, interlocking, and alarm signals
7. Analog interface, receiving 0-10V, 4-20mA given speed control signals

8. Built in complete hardware protection for overcurrent, overvoltage, short circuit, and overheating
9. Support automatic motor identification and quickly complete motor parameter tuning
10. Equipped with fault memory storage, facilitating equipment fault tracing and analysis
11. Support multiple fieldbus and interface with the upper PLC monitoring system
12. Cabinet wall mounted installation, compact structure, saves installation space
13. Wide temperature working range, suitable for high temperature working conditions of industrial cabinets
14. EMC electromagnetic compatibility to resist on-site electromagnetic interference from frequency converters
15. Multiple units can be connected in parallel to meet the high-power multi motor transmission scheme
TDE MACNO AC/DC50 industrial driver, AC/DC compatible speed control unit, widely used in transmission control systems for heavy industry equipment, extrusion machinery, and special equipment.

Product detailed pictures：

AC/DC50
