TEL 2L08-05105-22 Printed Circuit Board
Product Manual：
TEL 2L08-05105-22 printed circuit board is a specialized transfer PCB for sensing and pneumatic control of Tokyo Electronic Semiconductor Equipment. TEL 2L08-05105-22 printed circuit board is responsible for sensor and valve group signal transfer and power distribution. Its 15 product features include:
High temperature resistant special substrate, clean cabinet is not easily deformed after long-term use
Multi layer partition wiring, separation of strong and weak electrical lines to reduce interference
Gold plated solder pads, not easily oxidized after repeated insertion and removal, stable contact
Multi channel signal circuit, converting pressure and flow sensing signals
Large area partition grounding, shielding cavity RF electromagnetic clutter
Slotted isolation of high and low voltage lines, in compliance with semiconductor insulation safety regulations
Onboard filtering components to suppress signal numerical fluctuation drift
Integrated current limiting protection circuit, short circuit is not easy to damage the board
Original standard socket, easy to disassemble and assemble machine wiring harness
Dense thermal conductive vias reduce the operating temperature rise of power components
Standard card size, quick replacement and installation of cabinet rails
Wide temperature adaptation for dust-free workshops, long-term operation without parameter deviation
Fully automatic SMT surface mounting process, with firm solder joints and reduced virtual soldering
Moisture proof solder mask protective layer, suitable for clean production environment
Full electrical testing at the factory, no debugging required for direct use on the machine
TEL 2L08-05105-22 printed circuit board compatible with etching and thin film equipment, is a specialized circuit board accessory for repairing and replacing pneumatic sensing control systems
Product detailed pictures：
