TEL 2L81-050105-V2 Printed Circuit Board
Product Manual：
The TEL 2L81-050105-V2 printed circuit board is a specialized signal control board for Tokyo Electronic Semiconductor Etching Equipment. The TEL 2L81-050105-V2 printed circuit board is compatible with the machine’s gas path and sensing signal acquisition system. The 15 product features are as follows:
Original factory high temperature resistant LCP substrate, which is not easily deformed during long-term operation in clean rooms
Multi layer partition wiring, separating power lines from weak sensing signals
Gold surface treatment, resistant to process trace corrosion and gas oxidation
Multi channel sensor signal acquisition circuit, real-time transmission of pressure and flow data
Large area zoning with copper grounding to shield the cavity from radio frequency electromagnetic interference
High and low voltage lines are slotted and isolated to meet the insulation safety regulations of semiconductor equipment
Integrated multiple interlock protection circuits for overcurrent, short circuit, and overvoltage
Original standard needle socket, securely plugged into and out of the cabinet wiring harness
Onboard filtering components to suppress signal numerical drift and fluctuations
Dense thermal conductive vias reduce the operating temperature rise of power components
Equipped with a dedicated bus line for the device, synchronously uploading process parameters
Standard card type, convenient disassembly and replacement of cabinet rails
Fully automatic SMT surface mounting, with uniform and firm solder joints that are not prone to virtual soldering
Wide temperature stable operation, suitable for workshop constant temperature continuous production conditions
Complete electrical aging testing at the factory, no need for re debugging on the machine
TEL 2L81-050105-V2 printed circuit board is a core PCB component for repairing and replacing electronic control systems in wafer processing equipment
Product detailed pictures：
2L81-050105-V2
